KODAK

      FLEXCEL SR Plates

            Outstanding Performance

Consistency

KODAK FLEXCEL SR Flexographic Plates have been designed to bring brand owners confidence that their packaging will be produced reliably and consistently, and to bring printers of packaging materials increased productivity and peace of mind. FLEXCEL SR Plates are part of Kodak's complete range of quality products for the packaging industry.

SR + DITR

Combine the outstanding performance of the FLEXCEL SR Plate line with KODAK DITR Film, a high quality digital no-process film.

SRH

FLEXCEL SRH Flexographic Plates are premium, high-durometer plates developed specifically for the most challenging jobs that have fine halftone line screen reproduction and solid printing requirements.

SRM

FLEXCEL SRM Flexographic Plates are premium, mid-range durometer plates, designed for fine halftone line screen reproduction and solid printing requirements, specifically developed to print on the widest variety of substrates, from tissue to flexible film.

SRC & SRC-K

KODAK FLEXCEL SRC and SRC-K Plates are low-durometer photopolymer plates ideal for halftone reproduction on coarse board


Plate

SRH

SRM

SRC

SRC-K

Plate thickness 1.14 mm / 0.045 in1.70 mm / 0.067 in2.28 mm / 0.090 in2.54 mm / 0.100 in2.72 mm / 0.107 in2.84 mm / 0.112 in 1.14 mm / 0.045 in1.70 mm / 0.067 in2.28 mm / 0.090 in2.54 mm / 0.100 in2.72 mm / 0.107 in2.84 mm / 0.112 in3.18 mm / 0.125 in 2.84 mm / 0.112 in3.18 mm / 0.125 in3.94 mm / 0.155 in 3.94 mm / 0.155 in4.70 mm / 0.185 in5.00 mm / 0.197 in5.50 mm / 0.217 in6.00 mm / 0.236 in6.35 mm / 0.250 in7.00 mm / 0.276 in7.50 mm / 0.296 in
Relief depth 0.5-0.7 mm / 0.020-0.028 in0.6-1.0 mm / 0.024-0.039 in0.7-1.5 mm / 0.028-0.059 in0.7-1.5 mm / 0.028-0.059 in0.7-1.5 mm / 0.028-0.059 in 0.5-0.7 mm / 0.020-0.028 in0.6-1.0 mm / 0.024-0.039 in0.7-1.5 mm / 0.028-0.059 in0.7-1.5 mm / 0.028-0.059 in0.7-1.5 mm / 0.028-0.059 in0.7-1.5 mm / 0.028-0.059 in0.7-1.5 mm / 0.028-0.059 in 1.4 mm / 0.055 in1.6 mm / 0.063 in1.9 mm / 0.075 in 1.9 mm / 0.075 in2.2 mm / 0.087 in2.3 mm / 0.091 in2.3 mm / 0.091 in2.5 mm / 0.099 in2.5 mm / 0.099 in2.7 mm / 0.106 in2.7 mm / 0.106 in
Durometer Shore A 1.14 mm: 70 - 761.70 mm: 61 - 672.54 mm: 57 - 632.72 mm: 57 - 632.84 mm: 56 - 62 1.14 mm: 67 - 731.70 mm: 57 - 632.28 mm: 54 - 602.54 mm: 51 - 572.72 mm: 50 - 562.84 mm: 50 - 563.18 mm: 50 - 56 2.84 mm: 37 - 423.18 mm: 35 - 403.94 mm: 32 - 37 3.94 mm: 32 - 384.70 mm: 34 - 405.00 mm: 34 - 405.50 mm: 33 - 396.00 mm: 33 - 396.35 mm: 33 - 397.00 mm: 32 - 387.50 mm: 32 - 38
Resolution 1 to 95% @ 150 lpi 1 to 95% @ 150 lpi 3 to 95% @ 133 lpi 3 to 95% @ 133 lpi
Isolated dot reproduction 100 – 130 μm 100 – 130 μm 150 – 200 μm 150 – 200 μm
Fine line reproduction 70 – 100 μm 70 – 100 μm 100 μm 100 μm
Wash-out solution Compatible with most wash-out solutions. Refer to manufacturer’s recommendations.
Dryer temperature 51 o  - 55 o C / 123.8 o  - 132 o  FFinal dry times will vary depending on the plate caliper, processing equipment and type of washout solution used.
Ink compatibility Aqueous, solvent-based, UV-cured and cationic inks.
Storage and handling Unopened plate packs should be stored flat and away from excessive cold, heat and humidity. Use in a controlled environment of 10 o  – 25 o C (50 o  – 77 o F) and 40 – 55% RH.
