Printing short run lengths economically
The EVO XD S/N is a new press concept designed at meeting growing demands for printing short run lengths economically. The CI press equipped with 6 or 8 printing decks stands out through its compact and robust design and a acknowledged high print quality from KBA-Flexotecnica whilst keeping the capital investment low.
A raft of new technical features as well as intuitive operation keep makeready times to a minimum and enhance productivity. Wrap-around labels, shrink sleeves, lidding films etc. are printed cost-effectively even in small print runs with the EVO XD S/N.
Whether film or paper, the dryer especially designed for this press guarantees good results at speeds of up to 350mpm. There are a raft of options available for tailor-made EVO XD S/N press configurations.
Small space requirement and outstanding print quality
User-oriented machine design with intuitive operator interfaces
Performance-enhancing, fast job changeover
Low investment costs combined with sustainable energy-saving package
Short makeready times, less waste
AIF Auto Impression Flexotecnica
Automatic control of print impression positions AIF with less than 30 metres of material waste assuring a quick and efficient production start-up.
ARF Automatic Register Flexotecnica
System to automatically control print registration. It is fully integrated into the operator touch screen.
Speedy Clean
Auto wash-up system “Speedy Clean” with digital control of all washing cycles from the touch screen panel.
Broad range of applications
The EVO XD is a universal printing press designed for processing plastic film, paper and board in a variety of print run lengths. Extra inks or coatings can be applied to both sides of a substrate with maximum register accuracy with additional single flexo or gravure printing decks. Further options include integrating an inline laminating or inline punching machine for processing board. The EVO XD permits extremely customer- and product-orientated configurations. This is a deciding factor for your economic success.
| Standard | Optional | |
|---|---|---|
| Printing units | 8 | 10 |
| Max. print width | 800 - 1,600 mm | - |
| Print cylinder repeat max. | 1,070 mm | - |
| Max. web speed | 400 m/min | 500 m/min |
| Web width | 850 - 1,650 mm | - |
| Colour systems | solvent, water, UV, EB | - |
| Reelstand | 800 - 1,000 mm | - |
| AIF - Auto Impression Flexotecnica | - | ü |
| ARF - Auto Register Flexotecnica | - | ü |
| Carbon fibre technology 1) | - | ü |
| Flexcolour Matching | - | ü |
| Quadtech Web Viewing System | - | ü |
| Quadtech Touch Register | - | ü |
| Quadtech CMS 2) | - | ü |
| SSC - Safe Sleeve Change | - | ü |
| Speedy Clean | - | ü |
1 printing roller and sleeve made of carbon fibre
2 in-line colour difference measuring (delta E)
