VERSAMARK Printing Systems
Embark on your journey to greater profitability with a monochrome system that prints transactional documents with limited amounts of variable information. Expand to a spot color that helps you highlight specific areas of interest. And finally, exceed your customers' expectations with exceptional full-color variable data printing that lets you fully personalize each and every transactional document or direct mail promotion.
Environmentally advantaged
KODAK VERSAMARK Printing Systems' Drop-on-Demand inkjet technology uses water-based inks and fluids. In addition, these innovative systems require only enough paper to run the job, reducing makeready waste and overages. By minimizing both pressroom waste and obsolete inventory, you will also reduce the amount of waste paper going to the landfill and realize quantifiable environmental benefits.
Environmentally advantaged
KODAK VERSAMARK Printing Systems' Drop-on-Demand inkjet technology uses water-based inks and fluids. In addition, these innovative systems require only enough paper to run the job, reducing makeready waste and overages. By minimizing both pressroom waste and obsolete inventory, you will also reduce the amount of waste paper going to the landfill and realize quantifiable environmental benefits.
Modular Upgrade Path
The KODAK VERSAMARK Printing Systems upgrade path allows you to start with a monochrome narrow platform and upgrade all the way to a 4 or 5 color wide on the same single engine platform design.
Security
Your brand is your most valuable corporate asset. Learn how digital printing solutions can help you protect it.
700 Print Manager
The KODAK 700 Print Manager is a digital front end that lets you run your press at peak performance - with easy set-up, a sophisticated job queue, early preflight checks, and on-the-fly job correction. Our scalable design lets you operate at speed using the minimal hardware required.
Capitalizing on Kodak's expertise in imaging and color science, the 700 Print Manager helps you achieve results that will delight your most demanding customers.
Technical Data
| General Specifications | |
|---|---|
| Print technology | Piezo electric Drop On Demand inkjet |
| Maximum print width | 18.67" (474 mm) |
| Ink / Supplies | Water-based dye inks, four color process (CMYK). Optional water-based pigment dyes are also available. |
| Resolution | 100 N/W, 300N/W System: 600 x 600 dpi 150N/W, 500N/W System: 600 x 360 dpi 1 |
| Speed | 100N/W, 300N/W System: 246 fpm (75 mpm) 2 150 N/W, 500N/W System: 410 fpm (125 mpm) 3 |
| Pre-post options |
Open architecture, slack web
|
| Processing options | Punch/Perf, selective perforation |
| Paper handling | 20.5" max web (520 mm) |
| Substrates | Compatible with a variety of substrates including inkjet treated and coated papers, and newsprint |
| Paper weight range | 16-42 lb. bond (60-160 gsm) and 45-48.8 gsm (newsprint) For applications requiring substrates above 32 lb. bond (120 gsm), please consult with your representative from Kodak |
| Controller options | KODAK 700 Print ManagerKODAK CS410 System Controller |
| Environmental operating ranges | |
| Temperature: | 68°F - 78°F (20°C - 26°C) |
| Relative humidity: | 40%-60%, non-condensing |
| Heat output: | 113,500 BTU/hr @ 50% dryer duty cycle |
| Audible noise: | less than 78 dB(A) |
| Altitude: | For locations above 3,000 feet (914 meters), please contact your local Kodak representative to arrange a site evaluation. |
| Power source | |
| Printer | Three phase 480VAC @ 125 Amp 60 HzThree phase 400VAC @ 180 Amp 50 Hz |
| Controller | Single phase 200 - 240 V, 12 A |
| Dimensions | |
| Height | 6.75 ft. (2,057 mm) |
| Length | 12.4 ft (3,780 mm) |
| Depth | 7.25 ft. (2,210 mm) |
| Weight | |
| Printing unit | (Preliminary — not to exceed) 8,500 lb. (3,856 kg) |
| Pad weight | 8 pads @ 1,063 lb. (482 kg) |
|
1 Also capable of running at 246 fpm (75 mpm) with resolution of 600 x 600 dpi 2 100N/W System is a monochrome printing system; 300N/W System is a full color printing system 3 150N/W System is a monochrome printing system; 500N/W System is a full color printing system |
|
